TECHNICAL DATA | ||
---|---|---|
DIMENSIONS | L x W x H (mm) FOLD SIZE |
1350x590x1080 1350x320x570 |
PRODUCT WEIGHT | Vehicle weight in running order (with battery) | 53 Kg |
CYCLING REQUIREMENTS | Maximum Speed Maximum distance with one charge |
40 Km/h 40 km |
VEHICLE PARAMETERS | Working temperature Storage Temperature |
-5-45 degree celcius -5-45 degree celcius |
BATTERY | Rated Volt Battery capacity Charging voltage Weight |
48 V 960 Wh 54.6 V 7.6 kg |
MOTOR | Rated power Torque |
1000 W 53.6 Nm |
CHARGER | Input voltage Rated output Voltage Rated current Charging time |
100-240 V 54.6 V 3 A 6 – 7 hours |
LIGHT | Headlight Tail light |
LED LED |
CONTROLLER | Rated Volt Limited current |
48 V 25 A |
SUSPENSION | Front Rear |
Earless front fork system Double shock absorber |
BRAKE | Front Rear |
Mechanical disc φ140 Mechanical disc φ140 |
TIRE | Size | Tubeless 135/65-8 |
FRAME | Materials | High-tensile steel |
CERTIFICATE | CE/EEC |
