TECHNICAL DATA | 250W | 500W | 750W | |
---|---|---|
DIMENSIONS | L x W x H (mm) | 1698x620x1195 |
PRODUCT WEIGHT | Vehicle weight in running order (with battery) | 28 Kg | 30 Kg | 32 kg |
CYCLING REQUIREMENTS | Maximum Load Full Speed Maximum distance with one charge |
100 Kg 25 Km/h 50 km |
VEHICLE PARAMETERS | Working temperature Storage Temperature |
-5-45 degree celcius -5-45 degree celcius |
BATTERY | Rated Volt Battery capacity |
48 V 624 Wh |
MOTOR | Rated power Rated Volt Torque |
250 W | 500W | 750 W 48 V 18 Nm | 38 Nm | 35 Nm |
CHARGER | Input voltage Rated output Voltage Rated current Charging time |
100-240 VAC 57.6 V 2 A 6 – 7 hours |
LIGHT | Headlight Tail light |
LED LED |
DISPLAY | Type | LCD |
TRANSMISSION SYSTEM | Shimano (7 speed) | |
CHAIN | 52T | |
HANDLEBAR | Materials | AL6061 |
DISC SIZE | Front Rear |
Hydraulic disc brake φ203 Hydraulic disc brake φ180 |
TIRE | Front and Rear | 20*4.0 |
FORK / FRAME | Materials | Aluminium alloy |
